The camera is precisely guided on a sled, assembly errors are excluded. The ergonomic arrangement of all important elements allows for convenient operation of the functions. For maximum safety, a generously sized 4mm O-ring and the well-proven SUBAL QuickLock closure system, which prevents accidental pinching of the O-ring, ensure maximum safety. The well-shaded monitor window provides a glare-free and high-contrast view of the camera monitor. Threads at the base and in the accessory shoe allow for the attachment of rails or pilot lamps, etc. The extensive equipment is complemented by excellent viewfinder optics. Optionally, both the magnifying viewfinder optics GS 180 and the also magnifying, 360° rotatable, viewfinder WS 45 can be installed. Material selection, processing, surface protection, and finish correspond to the usual quality level that has led to the proverbial reliability of SUBAL products.
All SUBAL front ports with bayonet connection can be used with this housing.
Technical Specifications:
Sea-water resistant aluminum alloy worked from the block, highest surface hardness, and corrosion resistance through hard coating. All parts made of hard-anodized lightweight metal, acid-resistant stainless steel, and highest quality plastics. Sealing through seamless precision O-rings. SUBAL QuickLock closure system.
Width x Height x Depth:
Approx. 255 x 170 x 140 mm
(without port and handles)
Flash Connection:
2 flash connection sockets: Optionally Nikonos V, IKELITE, or subtronic S6 flash sockets connected in parallel, TTL function ONLY possible with S6 socket and original Canon flash unit!
Flash Arm Attachment:
2 T-plates 25 mm, TLC- or Ultralight shoe optional
Transmissions and Functions:
Main switch, shutter release, zoom (manual focusing), front and rear control wheel, lens release, program mode, AF-ON, cursor.
Buttons for:
Light, Metering mode-white balance, AF-Drive, ISO-flash power correction, Menu, Playback, Delete, Jump, Info, Picture Style, Set, AF point selector, Exposure memory, Live View
